Seetronic-SE8FF-02-C6A Select New
Seetronic SE8FF-02-C6A is a professional RJ45 feedthrough adapter designed for reliable Ethernet cable linking in demanding installation and entertainment environments. Supporting CAT6a performance and PoE++ (IEEE 802.3bt), this adapter ensures stable high-speed data transmission and dependable power delivery for modern network-based systems.
Compatible with Seetronic SE8MC-02-NEW cable connectors, the SE8FF-02-C6A features a compact and...
Product Information
SKU: 1621000268
GTIN: 810087374846
HS-Code: 85444290
Seetronic SE8FF-02-C6A is a professional RJ45 feedthrough adapter designed for reliable Ethernet cable linking in demanding installation and entertainment environments. Supporting CAT6a performance and PoE++ (IEEE 802.3bt), this adapter ensures stable high-speed data transmission and dependable power delivery for modern network-based systems.
Compatible with Seetronic SE8MC-02-NEW cable connectors, the SE8FF-02-C6A features a compact and lightweight design that is ideal for space-constrained installations. Its durable construction, latch-lock mechanism, and IP65-rated protection make it well suited for professional lighting, audio, and network infrastructure where robust and consistent connectivity is essential.
Gallery
Specification
- • Connection Type: RJ45 Adapter
- • Contact Resistance: < 10 mΩ
- • Rated Current: 2A
- • Rated Voltage: 60V
- • Insulation Resistance: ≥ 0.5GΩ
- • Dielectric Strength: 1KV DC
- • Frequency Range: 1~100 MHz
- • Transmission Performance: CAT6a
- • Ethernet Power Supply: PoE++ accdg. IEEE 802.3bt
- • Insertion Force: ≤ 20 N
- • Service Life: > 1000 mating cycles
- • Locking Device: Latch Lock
- • Contacts: Copper Alloy
- • Insert: PBT
- • Contact Surface: Au
- • Panel: Zinc Alloy
- • Temperature Range: -30°C ~ +80°C
- • Environmental Protection: IP65
Specifications subject to change without notice
