VMS4- Velocity Midi Station Archive
Digital Work station
The VMS4 (Velocity MIDI station) is an optimal fusion of a high-quality, digital 4 channel mixer and a MIDI Controller with integrated soundcard. This makes the VMS4 both the ideal, modern DJ software MIDI controller as well as a full value digital 4 channel mixer with phono/line inputs. The tough workmanship of the VMS4 makes it ideal for use on the demanding club circuit. Highquality faders, that are exchangeable both in the channel strip as well as in the X-Fader area, an adjustable X-Fader curve, a channel based 3-band EQ and symmetrical XLR outputs are professional features for the serious user. Features such as the integrated Mousepad make it perfect for handling a
PC. With over 100 MIDI controllers and keys, the controller offers optimal control of all DJ-software. All MIDI controllers can be dual accessed and are mainly lit. The VMS4 is “TRAKTOR compatible". If you already own TRAKTOR you can download the Midi Command Files from our Download section below. Further highlights are the possibility of the application of digital PC effects on the analog channels, the touch-sensitive Jog Wheels with 2000 dpi resolution and two 10-bit pitch Touchpads.
- General Features: - Midi Controller with 4 USB / Analog selectable MIDILOG (Midi & Analog) channels
- - All audio control faders, knobs, switches, and buttons smoothed- eliminates popping, wiper noise, and zipper noise - On/off soft startup and turnoff - Gain/treble/mid/bass EQ on all MIDILOG channels - 2 phono/line selectable analog channels - Two microphone channels with illuminated on/off switches and gain/treble/mid/bass EQs - On/off cueing on each MIDILOG channel - Split cueing headphones with rotary mix control - Illuminated rubber knobs for ease of use in dark environments - Solid 1.6mm thick faceplate for extra durability - Panel mounted rotary knobs - Full analog mixer operation if the computer crashes or with external power supply - Innofader replaceable crossfader compatible (sold separately) - Crossfader curve control - Crossfader assign and reverse - Q-Start crossfader controlled startup for 2 external audio players - User replaceable channel faders - Master and Booth outputs with L/R balance - Balanced Master outputs - 12 position stereo master output VU meter - incl. virtual DJ LE Software - Dimensions (LxWxH): 320x486x65mm Midi Features: - Built-in mouse pad - Long life MIDI assignable touch strips - Two 10- bit resolution pitch sliders - 62 assignable MIDI buttons and switches - 50 MIDI buttons have LED illuminations, including 18 with dual blue/red LEDs - 4 assignable rotary encoders - 34 assignable rotary controllers - 5 assignable linear fader controllers - Dual MIDI controls on all buttons and switches - Dual 2000 point resolution touch sensitive turntable scratch controllers Audio Features: - 24-bit 48 kHz analog audio - 16-bit 44.1kHz USB audio - 10-bit resolution on all analog fader controls - THD <0.1%* - Channel separation >60dB* - S/N ratio >85dB* - Analog channel audio latency < 1msec - Selectable USB modes: 4 in 4 out mode for running software effects on phono/line analog channels or 2 in 8 out mode for running 4 software channels and master recording * For each audio channel, both line and phono modes
