CPX 15A Archive
Product Information
SKU: 1161350011
GTIN: 819730017321
HS-Code: 8518220090
Gallery
Specification
- Features:- 2-way Speaker with High Efficiency Class D Amplifier.- 500W Built-in Bi-amplifier - Time Aligned Electronic Crossover- 5 M8 Rigging points- Stand Mountable- Heavy Duty steel grill- Ergonomic handles- Power and Clip LED Indicators- XLR and RCA inputs- XLR and TRS throughputs- Clipping and Thermal Protection
- - Output Sensitivity: 94dB(1m/1w¬¬)- Max. SPL: 114dB- Balanced Input Impedance: Line 20K?, Mic 3.6K?- Unbalanced Input Impedance: Line 10K?, Mic 1.8KΩ
- Crossover:- Low Pass: 2nd order filter 2.7KHz- Low Cut: 2nd order filter 30Hz
- Channel Equalizer:- Bass: 100Hz +/- 12dB- Treble: 10KHz +/- 12dB
- - Multi Voltage Switch: AC 115V/60Hz or 230V/50Hz - Dimensions (LxWxH): 456 x 390 x 680mm- Weight: 28 kg
